15Kw Vibrating Screen Machine 120 TPH Soil Clay Bucket Mobile Sand Washing Machine

Ask Lasest Price
Brand Name :	RUNWELL
Model Number :	XS-3016
Certification :	CE,ISO certificates
Price :	USD 20000-25000
Payment Terms :	T/T, Western Union, L/C, MoneyGram
Supply Ability :	30 sets per month
Delivery Time :	20 working days

Add to Cart

Product Details
Company Profile

15Kw Vibrating Screen Machine 120 TPH Soil Clay Bucket Mobile Sand Washing Machine

Bucket Gravel Stone Soil Clay earty sand Washer Rock Sand Washing Machine in Philippines

Product Description

　　The bucket wheel sand washer cleans and separates stone powder and dust. Its novel seal structure and reliable gearing ensure the cleaning and dehydration effects. The sand washer is a kind of high efficiency sand washing equipment operated with sand maker. This series of sand washer features the following advantages: rational structure, convenient maintenance, great handling capacity, low power consumption and high washing cleanliness.

15Kw Vibrating Screen Machine 120 TPH Soil Clay Bucket Mobile Sand Washing Machine

Working Principle

　　Sand washing machine equipment drives the impeller in the water groove to move like a circle transmitted by electric motor and decelerator, and then mixes, overturns, cleans and discharges the sand or slag pellets in the water groove.

Zenith sand washing machine equipment, sand washing machine with CE

Competitive Price New Design Hot Product Model Wheel Sand Washers
For Muddy Sand

Products Description

The sand washing machine production line is usually composed of
feeders, crushers, drum screens, water washing wheels, belt
conveyors,centralized electrical control and other equipment.
This machine is widely used for washing materials in industries
such as gravel yard, mining, building materials, transportation,
chemical industry, water conservancy and hydropower,and concrete
mixing station.

Performance Features

1.The structure of the machine is simple, and the impeller drive
bearing device is isolated from water and water-receiving
materials,which greatly avoids the damage of the bearing.
2.There is very little loss of medium-fine sand and stone powder,
and the grade and fineness modulus of the washed building sand
meet the standards for building sand,building pebbles, and gravel.
3.The machine has almost no wearing parts.
4.Long service life, no maintenance for a long time.

15Kw Vibrating Screen Machine 120 TPH Soil Clay Bucket Mobile Sand Washing Machine

Specification

Model	XS2610	XS2610II	XS2800	XS3200	XS3600
Diameter of The Wheel Bucket(mm)	2610	2610	2800	3200	3600
Rotation Rater (r/min)	2.5	2.5	1.2	1	1
Maximum Feeding Size(mm)	≦10	≦10	≦10	≦10	≦10
Processing Capacity(t/h)	20~50	30~70	50~100	80~120	120~180
Motor Power (kw)	5.5	5.5	7.5	11	15
Overall Dimensions(mm)	351520702672	35152070 2672	39003300 2990	39654440 3410	43554505 3810
Weight (kg)	2500	2900	3980	7270	9430

Specification

Model	Screw diameter(mm)	Length of Chute (mm)	Max feeding size(mm)	Capacity (t/h)	Speed (r/min)	Power (kw)	Water Consumption(t/h)	Overall dimension(L×W×H)(mm)	Weight(t)
XL508	508	6705	≦10	20	38	5.5	6-60	800023431430	2.67
XL610	610	7225	≦10	40-50	32	7.5	6-63	800020501400	3.80
XL762	762	7620	≦10	50-75	26	11	9-63	854526503862	5.23
XL920	920	8026	≦10	100	18	11	10-80	8715X1632X2075	4.6
2XL920	920	8026	≦10	150-180	18	2*11	20-160	8715X2602X2075	7.9
XL1115	1115	8532	≦10	175	18	15	20-150	9231X1833X2126	5.6
2XL1115	1115	8532	≦10	200-250	18	2*15	40-300	9231X2995X2126	10

15Kw Vibrating Screen Machine 120 TPH Soil Clay Bucket Mobile Sand Washing Machine

Questions & Answers
1. How long is the delivery time of your product?
The delivery time is within 20 working days.

2. What is the payment term?
The payment term is T/T.

3.How long is the product warranty period?
Our warranty period is 1 year, excluding wearing parts.

4.What's the after sale service of your company?
We will provide foundation drawing to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.

5. Can your company provide wearing parts?
We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
