The cone crusher not only improves the production capacity and
crushing efficiency, but also widens the applying area, from
limestone to basalt, from stone production to various ore crushing.
It has a second-to-non crushing performance in the work of
medium-size crushing, fine crushing and super fine crushing. The
crusher is the improved type of spring cone crusher and can be used
to replace ordinary hydraulic cone crusher .
Working Principle
Hydraulic cone crusher working principle :When HP series
multi-cylinder hydraulic cone crusher works, the motor drives the
outer copper rotate through V-belt, host pulley, drive shaft, a
small bevel gear, a large bevel gear. The outer copper forces
crushing cone shaft axis of the outer copper to make rotating
swing, making crushing surface.
Sometimes near and sometimes leave the concave surface, so that the
material is impacted, squeezed and bent in the ringlike crushing
chamber consist of fixed cone and movable cone. After repeated
squeezed, shocked, and bent, the material crushing to the required
particle size is discharged from the lower part.
The particular crushing chamber adopting principle of intergranular
lamination and matching rotor speed obviously improves the crushing
ratio and productivity, largely increase the amount of cubic final
product. Adopting hydraulic protection and hydraulic cavity
clearing, high degree of automation, the hydraulic system can be up
top and discharge automatically when the crusher is blocked
instantly or over-iron, which eliminates trouble of halting to
clear the material manually. It makes the maintenance more easier,
cost lower. The hydraulic adjustment and oil lubrication make the
crusher more steady and reliable. It also adopts labyrinth sealing
mode, which avoids oil mixing with water easily.
Specification
Model | Cavity | Standard Type | Short Type | Power | Capacity (t/h) |
Feeding Size (mm) | Min Discharging Size (mm) | Feeding Size (mm) | Min Discharging Size (mm) | (kw) |
HP200 | Super coarse | | | | | 132-200 | 90-250 |
Coarse | 185 | 19 | 76 | 10 |
Medium | 125 | 17 | 54 | 6 |
Fine | 95 | 13 | 23 | 6 |
Super Fine | | | 10 | 5 |
HP300 | Super coarse | 230 | 25 | | | 180-250 | 115-440 |
Coarse | 210 | 20 | 75 | 10 |
Medium | 150 | 15 | 50 | 8 |
Fine | 105 | 10 | 20 | 6 |
Super Fine | | | 20 | 6 |
HP400 | Super coarse | 295 | 30 | | | 280-355 | 140-630 |
Coarse | 250 | 25 | 90 | 10 |
Medium | 195 | 20 | 50 | 8 |
Fine | 110 | 14 | 40 | 6 |
Super Fine | | | 30 | 6 |
HP500 | Super coarse | 330 | 30 | | | 355-450 | 175-790 |
Coarse | 285 | 25 | 90 | 13 |
Medium | 200 | 20 | 55 | 10 |
Fine | 133 | 16 | 40 | 8 |
Super Fine | | | 35 | 6 |
HP800 | Super coarse | 353 | 32 | | | 550-630 | 260-1200 |
Coarse | 297 | 32 | 155 | 13 |
Medium | 267 | 25 | 92 | 10 |
Fine | 219 | 16 | 33 | 6 |
Super Fine | | | | |
Questions & Answers
1. How long is the delivery time of your product?
The delivery time is within 20 working days.
2. What is the payment term?
The payment term is T/T.
3.How long is the product warranty period?
Our warranty period is 1 year, excluding wearing parts.
4.What's the after sale service of your company?
We will provide foundation drawing to the clients for installation.
Besides, we can provide guidance service for installation and
operation of workers, etc.
5. Can your company provide wearing parts?
We can deliver you the spare parts within 10 working days after
your order. If your equipment are not manufactured by our company,
please provide us the wearing parts drawing or number.
