Stone Ore Mining Compound Cone Crusher For Hard Stone Mining 1650
Cone Crusher
Stone Ore Mining Compound Cone Crusher For Hard Stone Mining 1650
Cone Crusher manufacturers
Product Description
ZX compound cone crusher is a high performance cone crusher relible performance and superior
quality.It has hydraulic clearing system,hydraulic opening
adjustingfunction,easy for changing movable and fixed
plate,dacreasing managemengt and maintence cost,It is widely used
for medium and fine crushing of
granite,basalt,disbase,cobble,cobblestone,iron,ore etc.which is
well received by customers.
Working Principle
ZX compound cone crusher manufacturer work, the rotation of the
motor through the pulley or coupling, drive shaft and the cone of
force in the eccentric sleeve moving around a fixed for rotary
movement, so that the cone crusher in the crushing wall and near
and sometimes leave is fixedly arranged on the regulating sleeve
rolling white surface, the ore constantly under attack in the
crushing cavity, extrusion and bending and crushing ore achieved.
At unbreakable foreign body through the crushing chamber or for
some reason compound cone crusher manufacturer is overloaded, the
spring system of insurance, the mouth of discharge increases,
foreign bodies from the crushing chamber is discharged, such as
blocking in row ore using cavity cleaning system, so that the
discharging continues to increase, so that the foreign body removal
of crushing cavity. Under the action of the spring, the gape is
automatically reset, the machine returns to normal work.
Cone Crusher is widely used in metallurgical industry, building
materials industry, construction industry, chemical industry and
silicate industry, applicable to crush various kinds of ores and
rocks of medium or above medium hardness, and cone crusher is of
big crushing ratio, high efficiency, large capacity, low cost, easy
adjustment, and used economically, etc. The reasonable part
selection and structural design extend crushers’ usage life, and
the final products of uniform particle size reduce the cycle load,
the medium to large-sized crusher, adopts the hydraulic
clear-cavity system, reduces downtime, and various types of crusher
cavity to better adapt to users’ needs.
Spring Cone Crusher Advantages and features:
High productivity; high quality;
Less machine stop time;
Easy maintenance and lost cost;
Unique crushing ability in primary, secondary and tertiary
crushing.
Specification
Compound cone crusher specification
| Model | Cavity Type | Stroke(mm) | Max.Feeding Size(mm) | Discharging Opening Adjusted Scope(mm) | Capacity(t/h) | Motor Power(kw) | Weight(t) |
| ZX1650 | Coarse | 34 | 300 | 35-65 | 280-610 | 250 | 35 |
| ZX1650 | Coarse | 34 | 260 | 30-60 | 2665-580 | 250 | 35 |
| ZX1650 | Medium Coarse | 34 | 240 | 25-60 | 240-550 | 250 | 35 |
| ZX1650 | Fine | 28 | 130 | 20-45 | 180-350 | 250 | 35 |
| ZX1400 | Coarse | 30 | 235 | 30-60 | 210-530 | 220 | 25 |
| ZX1400 | Medium Coarse | 30 | 215 | 25-50 | 200-500 | 220 | 25 |
| ZX1400 | Medium Coarse | 25 | 180 | 22-45 | 180-475 | 220 | 25 |
| ZX1400 | Fine | 25 | 100 | 19-40 | 130-260 | 220 | 25 |
| ZX1200 | Coarse | 22 | 180 | 19-50 | 110-250 | 132 | 16 |
| ZX1200 | fine | 15 | 80 | 16-40 | 80-180 | 132 | 16 |
