    80-100 T/H Rock Hammer Crusher Machine For Mining Metal Sand Rock Stone Construction

    Ask Lasest Price
    Brand Name : RUNWELL
    Model Number : PC15-132 hammer mill
    Certification : CE and ISO
    Price : USD 50000-55000
    Payment Terms : T/T, Western Union, L/C, MoneyGram
    Supply Ability : 20 sets per month
    Delivery Time : 10-20 working days
    • Product Details
    • Company Profile

    80-100 T/H Rock Hammer Crusher Machine For Mining Metal Sand Rock Stone Construction

    Hammer Mill for Metal, Sand, Rock, Stone Construction, Mining 80-100 T/h
    Hammer Crusher/Stone Crusher/Sand maker/Quarry Crusher
    Hammer crusher

    The coarse grinding mill is widely used in metallurgy, mining, chemical, cement, coal, dry stone, construction, sand, refractories and ceramic industrial and mining enterprises, engaged in breaking and crushing the material in the operation. It is mainly suitable for crushing compression strength not higher than 320MPa (MPa) of various soft and hard ore.

    Coarse grinding mill Performance and Features
    1. High capacity, big crushing ratio;
    2. Low power consumption, uniform granularity;
    3. Mechanical structure is simple, easy to use;
    4. Investment costs less, more Convenient Management.

    80-100 T/H Rock Hammer Crusher Machine For Mining Metal Sand Rock Stone Construction

    Product Parameters

    Technical Specifications of coarse grinding mill:

    ModelRotor diameter
    (mm)
    Rotor length
    (mm)
    Rotor speed
    (r/mm)
    Feed head size
    (mm)
    Max feed size
    (mm)
    Fineness(mm)Processing
    (t/h)
    Motor Power
    (Kw)
    The number of hammerDimensions L*W*H
    (mm)
    PC08-75750800800-1000320×930<500-310-3055-75182310*1665*1610
    PC12-909001200800-1000400×1200<500-330-6075-90322840*2100*2020
    PC15-13211501500550-800500×1500<1000-860-100110-132323720*2650*2540

    Note:This specification is just reference,any changes are subject to the Coarse Grinding Mill products.

    Coarse Grinding Mill Working Principle
    The coarse grinding mill is mainly consist by the frame, rotor, impact plate, grate bars and other components. Machine frame is divided into two parts, it is welded by steel plate after cutting, the other parts are connected by bolts. There are high manganese alloy liner inside the frame, easy replacement after wearing; Several sets of hammer are installed on the main shaft, they are connected by high-strength bolts. The main machine is running by motor and v-belt, then led the rotor spinning, large material enter to the crushing cavity from feed pole, will be crushed repeatly by rotor and hammer, then the qualified final products.

    Leave your Message,We will reply with in 24 hours!


    Product Parameters

    The Most Hot-Sale Hammer Crusher for Stone&Rock

    Questions & Answers
    1. How long is the delivery time of your product?
    The delivery time is within 20 working days.

    2. What is the payment term?
    The payment term is T/T.

    3.How long is the product warranty period?
    Our warranty period is 1 year, excluding wearing parts.

    4.What's the after sale service of your company?
    We will provide foundation drawing to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.

    5. Can your company provide wearing parts?
    We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
