    Carbon Steel Vibrating Pan Feeder ZSW420*110 Vibro Grizzly Feeder

    Ask Lasest Price
    Brand Name : RUNWELL
    Model Number : ZSW110*420
    Certification : CE,ISO certificates
    Price : USD 10000-15000
    Payment Terms : T/T, Western Union, L/C, MoneyGram
    Supply Ability : 50 sets per month
    Delivery Time : 10-20 working days
    • Product Details
    • Company Profile

    Carbon Steel Vibrating Pan Feeder ZSW420*110 Vibro Grizzly Feeder

    Product Description

    Vibrating Feeder /Crusher feed /Quarry Crusher plant
    Vibrating Feeder
    The ZSW and GZD vibrating feeder is a linear feeding equipment widely used in mining, building materials, chemical and silicate industry in crushing and screening plants. It features reliable, low-vibration operation and a long service life.

    Vibrating Grizzly Feeder for Quarry Plant Vibrating Grizzly Feeder for Quarry PlantVibrating Grizzly Feeder for Quarry PlantVibrating Grizzly Feeder for Quarry Plant

    Vibrating Feeder Working Principle:

    Our vibrating feeder consists of feeding trough, vibrator, spring, motor and so on. The vibration source of material feeding is vibrator, which is made up of two eccentric shafts (active and passive) and gear pair. The main shaft is driven by the motor through V-belt, and the passive shaft starts rotating through the gear meshing of the active shaft. Then the counter-rotating shafts force the feeder to vibrate. Through the vibration, the materials will slip and sling on the funnel, moving forward, when the materials pass the screening part, smaller parts will fall down, completing material feeding and separating.

    if you have any questions,plese contact us,we will reply with in 24 hours!
